| ブランド名: | Womeng |
| モデル番号: | WM-SLP01 |
| MOQ: | 1 |
| 価格: | $800,000.00-$9500,000.00 |
| パッケージの詳細: | 耐航性のある木製の箱 |
| 支払条件: | L/C、D/A、D/P、T/T、Western Union、MoneyGram |
| Product size | 40m*6m*4m (for reference only) |
|---|---|
| Product structure | Upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven, ADL (Acquisition distribution layer) non-woven, leak guard hydrophobic non-woven back sheet, Waist band non-woven, color pattern sticker, elastic waist band, discarding sticker. |
| Control system | PLC control system, HMI Operating on the LED touch screen, Configure HDTV monitor |
| Drive system | Servo Drive (Easy to change size), timing belt and flat belt are import products, and all the key parts are import bearings. |
| Tension system | Top tissue paper, bottom tissue paper, hydrophobic nonwoven (leg cuff), top nonwoven, ADL, back sheet, elastic nonwoven are adopt A&B shaft active unwinding by inverter motor. |
| Safety system | Safety device on the operating side, matched with urgent stop switch. High audio fan uses sound insulation or silencer. |
| Packaging system | According to customer requirements with palletizer machine (double push double exit) adjustable |
| Materials corrective system | Adopt international famous brand deviation correction system |
| Power | 380V, 50HZ three phase five wire |
| Machine Capacity | 400KW (Excluding glue machine and air compressor) |
| Bleed pressure | 0.6-0.8Mpa (Air compressor needs to be prepared by customers) |
| Machine weight | 100 Tons approximately |
Precisely match the core functions of menstrual pants to ensure product competitiveness
Double guarantee of leak-proof and fit: The production line, in response to the core demand of "high-waisted anti-side leakage" for menstrual pants, adopts precise elastic waist compression technology and three-dimensional protective forming technology. It can stably produce high-waisted silhouettes that fit the curve of the buttocks (the waist height can be adjusted to 25-35cm as needed), while ensuring the uniform fit of the widened anti-side leakage edge (3-5cm wide). Effectively reduce the risk of lateral and posterior leakage of menstrual blood, and the product experience meets the standards of medical care grade. For instance, the night-wear period pants produced for Southeast Asian customers have been tested to have a side leakage rate of less than 2%, which is significantly better than the local market average.
Strong compatibility with skin-friendly materials: It can be compatible with various skin-friendly surface layer materials such as pure cotton, bamboo fiber, and breathable non-woven fabric, and can precisely control the pressure of fabric adhesion to avoid skin irritation caused by damage to the fiber structure during the production process. In response to the demands of the European and American markets for "probiotic addition" and "antibacterial fabrics", the production line reserves a functional additive addition station. Without any modification, it can achieve a stable combination of special materials and functional components, helping buyers create differentiated products.
Contact Information:
Whatsapp: +008615805080212
Email: jessie@wm-machinery.com
Website: https://www.diapersmachines.com
