| ブランド名: | Womeng |
| モデル番号: | WM-FJA02 |
| MOQ: | 1 個 |
| 価格: | $500,000.00-$800,000.00 |
| パッケージの詳細: | 海上用木箱 |
| 支払条件: | L/C,D/A,D/P,T/T |
Product Info
|
Product size
|
M: 680X450 L: 800X650 XL: 950X760(Customixed according to customer requirement)
|
|
Product structure
|
Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker. |
|
Control system
|
PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
|
|
Drive system
|
Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
|
|
Tension system
|
Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B
shaft active unwinding by inverter motor. |
|
Safety system
|
It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
|
| Packaging system | according to customer requirements with palletizer machine (double push double exit ) adjustable |
|
Materials corrective system
|
Materials corrective system: Adopt international famous brand deviation correction system |
|
Power
|
380V, 50HZ three phase five wire
|
|
Machine Capacity
|
400KW (Excluding glue machine and air compressor)
|
|
Bleed pressure
|
0.6-0.8Mpa (Air compressor needs to be prepared by customers)
|
Quanzhou Womeng Intelligent Equipment Co., Ltd. is located in Quanzhou, the cultural capital of East Asia and the starting point of the Maritime Silk Road. Founded in 2016, it is an enterprise focusing on the R&D, manufacturing and sales of paper equipment. The products cover sanitary napkin equipment, diaper equipment, pant equipment, mattress equipment, pad equipment, etc.
The company has excellent products, professional sales and technical teams, complete supporting facilities, and according to different market product specifications, each equipment is customized according to the actual needs of users, and has rich experience and technical capacity in the design and production of equipment.
Adhering to the business philosophy of honesty, cooperation and win-win, the company wholeheartedly provides high-quality products and services for new and old customers to meet the needs of customers to the greatest extent. Serving customers and achieving customers, "pioneering and innovating, pursuing excellence" is the constant pursuit of Womeng Equipment. We sincerely look forward to cooperating with new and old customers to create the future!
Whatsapp: +008615805080212
https://www.diapersmachines.com
Stable and efficient production performance
High continuous operation: The equipment has a solid structural design, reducing downtime caused by component wear or material jamming. The effective production time per day can reach over 20 hours, making it suitable for large-scale order demands.
Compatible with multiple raw materials: Compatible with conventional materials such as non-woven fabrics and absorbent cotton cores of different thicknesses, it can switch product specifications (such as diapers of different sizes and absorption capacities) without frequent parameter adjustments, flexibly responding to diverse customer orders.
The product quality is highly controllable
Uniform lamination process: By optimizing the lamination and cutting processes, it ensures that key parts such as the waist circumference and leak-proof edge of the diaper are closely adhered, reducing defects such as "crooked edges" and "broken lines" during production, and maintaining a stable finished product qualification rate of over 98%.
Absorption performance guarantee: The equipment strictly controls the laying density and distribution accuracy of the water-absorbing layer. The produced diapers have uniform water absorption speed and water retention, reducing the risk of side leakage for end users and enhancing the user experience.
It is convenient to operate and maintain
Simple human-machine interface: The control panel adopts a multi-language (English, Spanish, Arabic, etc.) operation interface, and parameter adjustment is intuitive (such as speed and size setting). Ordinary workers can operate it proficiently after 1-2 weeks of training.
Generalization of vulnerable parts: Core vulnerable components (such as blades and conveyor belts) adopt international standard dimensions. Customers can purchase and replace them locally without relying on original factory supplies, reducing maintenance costs and downtime.
