| ブランド名: | Womeng |
| モデル番号: | WM-FSS01 |
| MOQ: | 1 個 |
| 価格: | $300,000-$400,000 |
| パッケージの詳細: | 海上用木箱 |
| 支払条件: | L/C,D/A,D/P,T/T |
Product Info
|
Product size
|
25m*2.5m*3m(for reference only)
|
|
Product structure
|
Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker. |
|
Control system
|
PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
|
|
Drive system
|
Servo Drive(Easy to change size), timing belt and flat be
|
|
Tension system
|
Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&Blt are import products, and all the key parts, are import bearings.
shaft active unwinding by inverter motor. |
|
Safety system
|
It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
|
| Packaging system | according to customer requirements with palletizer machine (double push double exit ) adjustable |
|
Materials corrective system
|
Materials corrective system: Adopt international famous brand deviation correction system |
|
Power
|
380V, 50HZ three phase five wire
|
|
Machine Capacity
|
400KW (Excluding glue machine and air compressor)
|
|
Bleed pressure
|
0.6-0.8Mpa (Air compressor needs to be prepared by customers)
|
| Machine weight | 50 Tons approximately |
Quanzhou Womeng Intelligent Equipment Co., Ltd. is located in Quanzhou, the cultural capital of East Asia and the starting point of the Maritime Silk Road. Founded in 2016, it is an enterprise focusing on the R&D, manufacturing and sales of paper equipment. The products cover sanitary napkin equipment, diaper equipment, pant equipment, mattress equipment, pad equipment, etc.
The company has excellent products, professional sales and technical teams, complete supporting facilities, and according to different market product specifications, each equipment is customized according to the actual needs of users, and has rich experience and technical capacity in the design and production of equipment.
Adhering to the business philosophy of honesty, cooperation and win-win, the company wholeheartedly provides high-quality products and services for new and old customers to meet the needs of customers to the greatest extent. Serving customers and achieving customers, "pioneering and innovating, pursuing excellence" is the constant pursuit of Womeng Equipment. We sincerely look forward to cooperating with new and old customers to create the future!
Whatsapp: +008615805080212
https://www.diapersmachines.com
Climate adaptability and durable design
High temperature and high humidity resistance
The electronic control system is equipped with a forced air cooling device (suitable for an ambient temperature of 40℃), and the key circuit boards are coated with three-proof varnish (moisture-proof, salt spray-proof, and mold-proof), which can still operate stably in the tropical rainforest climate of Brazil and the high-humidity coastal environment of Venezuela (with a failure rate 50% lower than that of competing products).
The mechanical transmission components are made of stainless steel (304L) to prevent rust caused by the dampness of the rainy season in South America. The maintenance cycle is extended to 6 months (3 months for traditional equipment), reducing the maintenance costs of remote factories in regions such as the Amazon.
Dust-proof and anti-interference optimization
Dust covers are installed on the exposed parts of the production line (to adapt to the dusty environment in the Pampas of Argentina and the deserts of Mexico), and the servo motors adopt sealed bearings to reduce equipment failures caused by sand and dust entering, ensuring continuous production in windy and sandy countries such as Peru and Chile.
Hygiene standards and intelligent upgrades
Basic hygiene design
The surface of the equipment is made of food-grade stainless steel (304), which is easy to clean and disinfect, meeting the hygiene requirements in the high-temperature and high-humidity environment of South America. The glue circuit system is fully enclosed to prevent the leakage and contamination of hot melt glue, which complies with the production standards for feminine hygiene products stipulated in Brazil's Consumer Product Safety Law.
Intelligent primary adaptation
Equipped with a 10-inch touch screen (supporting Spanish/Portuguese), the operation interface is graphically guided, and local workers can master the basic operation within one week. Integrate the "Production data statistics function", automatically record data such as production capacity and yield rate, and help enterprises in countries like Chile and Uruguay achieve basic information management.
